Tube Notching Templates

Name: Tube Notching Templates
SKU: 2839
Availability: InStock
Rating: 5.00 (1 reviews)

Rated 5.00 out of 5 based on 1 customer rating

(1 customer review)

Price range: $29.00 through $57.00

*NEW* LASER INSERT FOR MOST TUBE SIZES!

Roll Cages, Chassis, Bumpers, All Tube Fabrication and Welding can benefit from this simple time-saving layout tool!

Slide our trace template over the tube and mark your cut line, easy peasy. No more guessing! Get the perfect cope every time, over and over.

For mock-up, you can also lay the notched end on an existing tube to determine if angle is sufficient or anticipate where your intersecting joints will be using our LASER INSERT!

Features:

Each template is labeled (size and degree)
Slot down the middle for centerline visibility and tube clocking
Chamfered edge to get a good sharpie mark all the way around
Made in the USA from durable PETG polymers

Each (8) piece set includes:

15 °
22.5 °
30 °
45 °
60 °
67.5
75 °
90 °

Available Tube Sizes:

0.25″
0.375″
0.50″
0.625″
0.75″
1.0″
1.25″
1.5″
1.625″
1.75″
2.0″
2.5″

Individual replacements are available, call or email sales@teryxoffroad.com

*PRO TIP – if your tube is undersized, simply use a rubber band to help hold the template while you mark it.

Tube Size:

Clear

SKU: N/A Categories: Made by us, Tube & Pipe Notching Templates

Additional information
Reviews (1)

Additional information

Weight	N/A
Tube Size:	0.25" TUBE, 0.375" TUBE, 0.50" TUBE, 0.625" TUBE, 0.75" TUBE, 1.0" TUBE, 1.25" TUBE, 1.5" TUBE, 1.625" TUBE, 1.75" TUBE, 2.0" TUBE, 2.375" TUBE, 2.5" TUBE, Laser insert 0.75", Laser insert 1.0", Laser insert 1.25", Laser insert 1.5", Laser insert 1.625", Laser insert 1.75", Laser insert 2.0", Laser insert 2.375", Laser insert 2.5"

1 review for Tube Notching Templates

Rated 5 out of 5

Frank L (verified owner) – January 15, 2025

Got my set in, ordered the wrong size but these will work on my other projects with 1.25 tubes. like how easy they are to use and no brain work, need a 90 degree pull out and quickly mark the tube.
